Dependig on the year, make and model, the mechanical fuel pumpis located on the lower right side of the engine (passenger side)next to the timing cover. It normally has two bolts mounting it,and two lines. Electric pumps are located in the fuel tank. Someunits have removable pump, others will have to be replaced withsending unit. Before you condemn the pump, check your fuses andrelays. Normally the horn and abs relay are interchangable. If theyare ok, check that you have ground and key on power at the fuelpump. This may be a two man job unless you have the right tools,because the fp signal only primes for a few seconds with key on.Chevys are known for having poor connectors at the fuel pump. Ifthat's the issue, replace the electrical connector about 8-10 insfrom the plug. good luck, i hope this helps you...jm.

How do you replace a fuel pump on an older Chevy 350?

A filter then cleans the fuel before it enters the high-pressure fuel pump. The pump then feeds a typical 43 psi (or optional 58 psi) fuel to the throttle body style EFI. The advantage of this system is that it is very easy to install, assuming there is room in the engine compartment. Typical In-Tank Electric Fuel Pump Installation Instructions D. FUEL PUMP INSTALLATION 1. Lubricate the fuel hose and pump outlet with a small amount of petroleum jelly. Place coupler and clamp on fuel pump and place second clamp on fuel hose. Place assembly upside-down on bench. Place rubber insulator on inlet of pump. Install pump.

take the fuel tank out of the vehicle. the pump is inside of the tank.

Where is the fuel pump 1994 Chevy 350 van?

It has a electric fuel pump inside of the fuel tank. YOU MUST REMOVE the tank to get to it.

How do you change the fuel pump on a 1978 Chevy 350?

Remove the hoses from your 1978 Chevrolet 350 cubic inch engine fuel pump. Remove the fuel pump belt. Remove the fuel pump retaining bolts. Reverse the process to install the new fuel pump.

Will a 1985 Chevy 350 work in a 1992 Chevy 350 for a replacement engine?

No it will not. Now it will bolt right in there but the transmission will not work and the fuel pump in the fuel tank has to much fuel pressure for a carburetor

Why cant you get gas to your 350 Chevy?

Plugged fuel filter, bad fuel pump, crimped, or plugged fuel line.

Does a 1997 Chevy 350 vortech have a fuel pump on the block or does it need a block off plate to cover where an fuel pump bolts onto the block?

All 1997 GM vehicles were fuel injected and all had the electric fuel pump mounted in the fuel tank. None had a mechanical fuel pump mounted on the engine block. A 97 Chevy 350 Vortec uses an electric fuel pump and sender assembly in the fuel tank. If it is a true 1997 block, then it doesn't have a place for a fuel pump on the block.

Can a 1995 Chevy 350 be used with a 1998 Chevy 350 fuel system?

No the fuel pressures are different 95 wasw about 10 psi 1998 is 60 psi . u need 2 change fuel pump

Will a fuel injection kit from a 98-99 Chevy 350 to your 74 Chevy 350?

No. You would have to switch the cylinder heads, fuel pump, and ad some computer equipment to operate the injection.

Why is my 96 Chevy 350 vortec not getting fuel in motor?

Need to check Fuel pump relay and fuel pump fuse. Also need to check fuel pump pressure. Is there fuel in the tank, Gauge may be lieing to you.

Where is the fuel pump relay on a 1992 Chevy pickup with a 350 motor?

The Fuel Pump Relay is inside the fuse box under the hood on driver side

Why is Chevy 350 carburetor losing fuel prime after stopping engine?

Bad accelerator Pump? Bad float? Wrong, fuel pump check valve. new fuel pump is on order, or add a check valve.

How can you get the push rod back into the block in a 1984 Chevy 350 if the old fuel pump was broken and the rod had fallen out?

You just put the fuel pump pushrod back in the hole and mount the fuel pump in place. No big deal. It's just held in there by the fuel pump.

Can you use a mechanical fuel pump on a 93 Chevy 350?

If you are running the fuel injection....absolutely not. No mechanical pump will provide the fuel pressure needed to run it. I don't even know if the 93 still has the mechanical fuel pump mount. Even if it did, the camshaft wouldn't have the fuel pump eccentric to run the pump.

Will a 1993 Chevy 350 block accept a mechanical fuel pump using a carburetor .not the original fuel injection.?

Yes, make sure it has the pin where the mechanical pump goes.

Can you miss the fuel pump rod on a 350 Chevy?

yes you can. of you tightened it up off the shaft pump damage probably occured or the shaft has bent.

How do you turn the fuel pressure up on your 350 Chevy?

i believe you would have to change the fuel pump.. i know that i had to replace it when changing out from TBinj to 4barrel carb

How do you ghange 350 Chevy fuel injected to carb?

Change the intake manifold and fuel pump... And naturally put a carb on top of the new intake.

What year did Chevy 350 stop fuel pump on block?

The same year they changed over to electronic fuel injection for all Chevy V-8 engines. Either 1984 or 1985.

Chevy 350 sputters and dies after driving a while 20 minutes?

sounds like you have a fuel pump issue. You forgot to mention the year of your car. it will depend if you have a mecanical or electric fuel pump.

How long should the push rod be for the fuel pump 1978 Chevy 350 be?

The rod should be 5.75 inches; assuming the correct year, size, and stock cam, fuel pump, etc.

Will a 1993 fuel injected 350 Chevy take a mechanical fuel pump?

All fuel injected engines from the 80's on use an electric pump. Most mounted in the fuel tank. No mechanical pump will put out the 40 plus PSI it takes to run injectors.

What needs to be changed when installing a 1987 fuel injected Chevy 350 into your 1978 Chevy Nova that has a carburated staight 6?

you need V8 motor mounts, bigger radiator, a turbo 350 or turbo 400 automatic tranny, a new driveshaft, the computer and wiring from the 350 fuel injected engines donor car and you should get a beefier rearend.

Electric Fuel Pump Install In Gm A Body Frame

Can your 1972 350 Chevy use an electric fuel pump?

Yes, it is done all the time. You need a low pressure pump that will pump at least 10 PSI. Then you will need a fuel pressure regulator installed in the fuel line just before the carburetor.

Where is the fuel pump relay on a 92 Chevy G20?

The fuel relay on a 1992 Chevy G20 5.7 liter, 350 is under the hood attached to the firewall at the top, just under the wind screen

Where is the fuel pump on a f 350?

Need to know the location of fuel pump on f 350 4 x 4

Where is fuel pump on 350 cu Chevy engine?

on 1979 gmc 350 cu in engine the mech'l fuel pump is on the passenger-side towards to front end of the engine. it mounts just above the oil pan. follow the gas line coming off the carburetor. this gas line will take you right to the mech'l fuel pump.

1995 Chevy 350 im not getting the signal to spray fuel to your injectors what would cause that besides the ecm and besides the ignition control mod and im getting oil pressure?

Fuel pump bad, Fuel pump relay not working, Fuel pump fuse bad.

Is there a difference between a carbuator camshaft for a Chevy 350 and a throtlebody camshaft for a Chevy 350?

not really, the difference in cams is more like a van versus a camaro. if you just want it to run, any cam will do, but if you want it to haul a$$, gotta go aftermarket... crane cams is good. there is a difference between them, though they interchange, if you put a cam from a 'k' code 350 5.7 in an old carbureted 350 pre 1987 , the mechanical fuel pump will not function…

What fuel injection does a 1996 Chevy 350 vortec engine have?

vortec trucks have MPI Multipoint fuel injection. yes it's not getting enough electic to the wires to fuel pump

What is the fuel pump pressure on a 1994 Chevy pickup with a 350 engine?

9 to 13 LBS. It can NOT be any higher are lower are you will have troubles.

Mounting Electric Fuel Pump

81 Chevy 350 motor runs for a while stops but doesn't start back up?

could be faulty fuel pump. located on front of motor. Or on worse side Cam may be bad. I had an 85 350 and similar problem. Mine was a weak fuel pump.

1994 Chevy 350 pu surging at idle powerbackfiring through throttle body during acceleration?

if it is a 350 tbi it sounds like the fuel pump is going out and won't last much longer. many people with same proble and the same fix, FUEL PUMP! Randy

Can a Chevy 5.7 350 carburetor engine fit in a truck that used a fuel injected engine?

YES BUT RUN A FUEL PRESSURE REGULATOR. YOU WILL ALSO HAVE TO HOT WIRE THE FUEL PUMP IF IT IS IN THE TANK.

Is the fuel pump on a 1986 Chevy pickup electrical or mechanical up?

The pump should be mechanical, mine is a 350 and it is mechanical, I should know it just went out last night

1988 Chevy 350 tbi idle adjustment?

simply put you can't if it is idleing not normal their is a problem surging/hunting idle=fuel pump/filter high idle =vacuum leak or sometimes fuel pump

Converting your vehicle from a mechanical fuel pump to an electric fuel pump system can help you avoid vapor lock issues, even out idle speeds and increase the torque of your engine by providing your engine with a reliable and constant fuel at an even temperature. You can place an electric fuel pump anywhere on the body of your vehicle where you can attach a ground wire to the frame. It will take about an hour to convert a mechanical fuel pump to an electric pump.

Step 1

Disconnect the negative cable from your car's battery and then remove the gas cap from your gas tank. Removing the gas cap will help to relieve pressure in the gas lines. Pump your gas pedal a few times to further dispel the pressure.

Step 2

Loosen the hose clamps connecting the fuel line from your tank to the mechanical fuel pump installed on the driver's side of your engine. The fuel pump is typically located near the front of the engine block toward the bottom (but above the oil pan). Place a glass jar under the hose connections to the fuel pump and then pull the hoses off the fuel pump; catch any gas that is still in the line in the glass jar. Make sure you also disconnect the line from the fuel pump to the carburetor or fuel injection system, and remove that hose completely. Plug up the open connections in your mechanical fuel pump with hose stops. A hose stop is a molded rubber cap with a hose clamp that is attached as if you were connecting a hose except it works as a stopper to prevent anything from entering or leaving the fuel pump. With the hose stops in place, your mechanical fuel pump is now disabled.

Step 3

Install your electric pump in its new location. Make sure it is placed somewhere where it will not be exposed to any flying road debris and is not in a passenger area of the vehicle; the trunk is a preferred location. Your pump will come with a bracket and sheet metal screws that you can screw right into the frame of your car. Use a drill to make driving the screws easier and make sure that the arrow printed on the electric fuel pump is pointing towards the engine compartment.

Step 4

Attach the black wire from the electric pump directly to the frame of the car by removing a nearby screw or bolt, passing it through the ring terminal at the end of the wire and then re-attaching the screw or bolt. This will ground the electric pump. Splice #12 wire to the red wire coming off the pump by twisting the bare wires together and covering the splice with electrical tape. Run this wire to the fuse box and attach it to the ignition fuse with a spade terminal connector. This will turn your fuel pump on when your ignition is engaged. Cut the wire and crimp the terminal to the end with your electrical pliers.

Step 5

Follow the fuel line that came from the old fuel pump back to where it connects to the feed line from the tank. Loosen the hose clamp and remove the hose. Attach the new fuel line from the tank to the electric pump with hose clamps. Then run the new fuel line from the electric pump to your carburetor or fuel injection system.

Cut the fuel lines in half, once between the fuel tank and the pump and then again from the pump to the engine. Install a universal inline fuel filter at each cut point attaching the hoses with hose clamps and making sure that the arrows on the fuel filters are pointed towards the engine.

Tip

• It is worth it to invest in a lined rubber fuel line, like those manufactured for fuel injection systems. While much more expensive initially then regular rubber hose, they will last longer as the inside lining will resist disintegrating from the gasoline.

Warning

• Do not smoke or use open flames when working on any portion of your vehicle's system that involves gasoline. Gasoline and its vapors are highly combustible.

How To Install Fuel Pump

Items you will need

• Flat head screwdriver
• Glass jar
• Hose stops
• Electric fuel pump
• Drill (if needed)
• #12 electric wire
• Ring terminal connectors
• Spade terminal connectors
• Electrical pliers
• Rubber fuel line
• Hose clamps
• 2 universal inline fuel filters
